Single Mast Aluminum Alloy Lift Platform

Single Mast Aluminum Alloy Lift Platform Standard Alloacation:

-Single Person Work

-Platform Max. Height Optional: 4m/6m/8m/10m

-Power Unit: AC 220V/50Hz

-Walk Way: Electric lifting/Manual walking

Instructions:

- Provide good support for the four outriggers of the platform before use.

- Power on, operate the lifting button on the top of the electric control box to lift the platform

- Operate the up button to raise the lifting platform. (When the platform is not raised, the motor reverses, just change the connection sequence of the power cord, the motor can rotate forward.)

- There is a remote control button on the top of the platform, which can also be raised and lowered while standing on the platform.

- The platform is equipped with an emergency lowering valve, which is used for emergency lowering operations after a power outage. Loosen the lowering handle counterclockwise by hand, and the platform can be lowered slowly. After tightening the lowering handle clockwise, the platform will stop lowering.

Safety:

- Explosion-proof valve: protect the hydraulic pipeline from rupture.

- Relief valve: to prevent high pressure when the machine rises. Adjust the pressure.

- Emergency lowering valve: it can be lowered in case of emergency.

Single Mast Aluminum Alloy Lift Platform Techical Specifications:
